Technical Details

• Features Pick and Place, Solder Retention
• Connector Type Header
• Voltage Rating 50V
• Current Rating (Amps) Varies by Wire Gauge
• Mounting Type Surface Mount
• Number of Positions 2
• Number of Rows 1
• Style Board to Cable/Wire
• Operating Temperature -40°C ~ 105°C
• Applications Automotive, General Purpose, Industrial, Medical
• Contact Type Male Pin
• Fastening Type Friction Lock
• Number of Positions Loaded All
• Termination Solder
• Material Flammability Rating UL94 V-0
• Contact Material Phosphor Bronze
• Insulation Color Natural
• Pitch - Mating 0.039" (1.00mm)
• Contact Finish - Mating Gold
• Contact Finish Thickness - Mating 30.0µin (0.76µm)
• Contact Finish - Post Gold
• Contact Finish Thickness - Post 3.94µin (0.100µm)
• Contact Shape Rectangular
• Insulation Height 0.213" (5.40mm)
• Shrouding Shrouded - 4 Wall
• Insulation Material Polyamide (PA), Nylon
