Technical Details

• Mounting Type Surface Mount
• Frequency Range 698MHz ~ 960MHz, 1.575GHz ~ 1.614GHz, 1.71GHz ~ 2.69GHz, 3.3GHz ~ 3.8GHz, 4.9GHz ~ 6GHz
• Applications CDMA, GSM, LTE
• Gain 4dBi, 0.98dBi, 1.93dBi, 2.3dBi, 3dBi
• Termination Solder
• Number of Bands 5
• VSWR 3
• Antenna Type Chip
• Height (Max) 0.125" (3.18mm)
• Frequency Group Wide Band
• Frequency (Center/Band) 829MHz, 1.5945GHz, 2.2GHz, 3.55GHz, 5.45GHz
• RF Family/Standard Cellular
