- Product Model C6D10065E
- Brand
- RoHS Yes
- Description DIODE SIL CARB 650V 35A TO252-2
- Classification Types of Rectifier Diodes
-
PDF
Inventory:2211
Pricing:
- 1 4.68
- 75 3.71
- 150 3.18
- 525 2.83
- 1050 2.42
- 2025 2.28
Technical Details
- Package / Case TO-252-3, DPAK (2 Leads + Tab), SC-63
- Mounting Type Surface Mount
- Speed No Recovery Time > 500mA (Io)
- Reverse Recovery Time (trr) 0 ns
- Technology SiC (Silicon Carbide) Schottky
- Capacitance @ Vr, F 611pF @ 0V, 1MHz
- Current - Average Rectified (Io) 35A
- Supplier Device Package TO-252-2
- Operating Temperature - Junction -55°C ~ 175°C
- Voltage - DC Reverse (Vr) (Max) 650 V
- Voltage - Forward (Vf) (Max) @ If 1.5 V @ 10 A
- Current - Reverse Leakage @ Vr 50 µA @ 650 V
